2D Engineering Drawings

Our 2D Engineering Drawing services deliver clear, detailed and accurate documentation of existing conditions and design intent. Whether you’re planning new construction, retrofitting an existing structure or verifying as-built conditions, AIMS provides industry standard 2D deliverables tailored to your specifications.

We produce a full range of engineering and architectural 2D drawings extracted from point cloud data or CAD design:

  • As-Built Drawings
    Capture the exact layout of existing structures, piping and systems.

  • Structural & Fabrication Drawings
    Detailing for steelwork, tanks, supports and custom components.

  • Piping & Instrumentation Diagrams (P&IDs)
    Accurate process diagrams of facility systems and instrumentation.

  • Isometric Drawings
    Pipe routing and fabrication-ready documentation.

  • Sections & Details
    Cross-sectional views for better spatial understanding and planning.

  • Floor Plans & Elevations
    Architectural and structural layouts for buildings and facilities.

Clarity in Every Line, Confidence in Every Project

Our 2D Engineering Drawings translate complex environments into clear, reliable documentation. When accuracy matters, you can count on us to deliver drawings that support smarter planning, seamless execution, and lasting results.
